CLOSED_B550 Gigabyte Aorus Pro (Bios: F16f (Aug 09, 2023)) | Ryzen 7 3700X | Sapphire RX5500 XT | USBMapping via SSDT
- Thread starter Fooose
- Start date
In the original post you have this note:
Can you elaborate on this? What's exactly turning this off is doing..?
BTW, I am running F12 BIOS on B550I and sleep works just fine. Your experience prevents me from upgrading to later BIOS versions.
Can you elaborate on this? What's exactly turning this off is doing..?
BTW, I am running F12 BIOS on B550I and sleep works just fine. Your experience prevents me from upgrading to later BIOS versions.
If your system runs well then stay on the F12 version, because all subsequent ones cause problems with Sleep. The error, what it is, no one has yet found or posted a solution.
"deactivate I2C and ESPI..." is no longer present in subsequent bios versions.
Thanks for posting, I have a few questions.
The OpenCore Install Guide said to remove DSDT.aml. Why did you put DSDT.aml in ACPI?
And why did you set whatevergreen.kext & SMCAMDProcessor.kext to false?
USBMap.kext/USBPorts.kext in kext folder is missing from config.plist, is there any problem with usb mapping even if I don't use it?
Your efi files are very useful to me. Thanks! ^^
The OpenCore Install Guide said to remove DSDT.aml. Why did you put DSDT.aml in ACPI?
And why did you set whatevergreen.kext & SMCAMDProcessor.kext to false?
USBMap.kext/USBPorts.kext in kext folder is missing from config.plist, is there any problem with usb mapping even if I don't use it?
Your efi files are very useful to me. Thanks! ^^
Last edited:
I use the DSDT to do my USB port mapping, it's easier to handle.
I don't need whatevergreen when I use SMBios "MacPro7.1".
I don't need SMCAMDProcessor as that is taken over by the AMD patches.
I hope I was able to help.
Have fun testing.
I think the link is wrong. ^^
Release OC-0.7.7_Release_AMD_B550AorusProEFI · Fooose/b550-Aorus-Pro
v0.7.7 Fixed rare crash caused by register corruption in the entry point Added ProvideCurrentCpuInfo support for Intel Alder Lake Fixed typo in Cpuid1Data recommendations for Intel Rocket Lake and...
github.com
The Link is correct and functional.I think the link is wrong. ^^
Thanks for your answer & effort! ^^
Release OC-0.7.7_Release_AMD_B550AorusProEFI · Fooose/b550-Aorus-Pro
v0.7.7 Fixed rare crash caused by register corruption in the entry point Added ProvideCurrentCpuInfo support for Intel Alder Lake Fixed typo in Cpuid1Data recommendations for Intel Rocket Lake and...
How is your project going? I see you only address 9 kext's in your config.plist and you have 15 kext's in your kext folder in EFI. You also reactivated the AMD specific kext's...
Is your system able to go to sleep now? I am on BIOS F12 and still can't go to sleep mode (starts power toggling). The culprit is GPP0 and not the USB I think. GPP0 should be top M.2 slot. I still haven't figured out why and how.
Everything seems work for me though except sleep and when I use the first DP port on my Vega64, my monitor will stay black when I turn it on. When I choose the 2nd DP port it works somehow.
I also added my USB port mapping. Because I saw you discussed it a lot with others.
Also added the Kext's I am using.
Is your system able to go to sleep now? I am on BIOS F12 and still can't go to sleep mode (starts power toggling). The culprit is GPP0 and not the USB I think. GPP0 should be top M.2 slot. I still haven't figured out why and how.
Everything seems work for me though except sleep and when I use the first DP port on my Vega64, my monitor will stay black when I turn it on. When I choose the 2nd DP port it works somehow.
I also added my USB port mapping. Because I saw you discussed it a lot with others.
Also added the Kext's I am using.
Attachments
HOW! xD I am also on F12 on B550 Aorus Pro and I can't get sleep to work. The wakeup calls are from GPP0 though, which is my Samsung 980 PRO SSD in the top M.2 slot.
