Ryzen 5 5600x RX 5500XT ASUS PRIME B550 Ventura 13.4 I am using AppleALC but its not just working. i have a soundcard ALC887 on my motherboard so layouts for this soundcard is 1, 2, 3, 5, 7, 11, 12, 13, 17, 18, 20, 33, 40, 50, 52, 53, 87, 99. i tried them all and only 11, 12, 13 can detect my aux headphones but the sound is still not working. if i put 12 sometimes it cant boot into mac. one time after waiting sometime after boot 12 started working but only headphones started working (without microphone) and after reboot it stopped working.
Aux devices are not working.
- Thread starter resefsew
- Start date
-
Hello Guest. Before you post check the Troubleshooting guide here, Dortania Troubleshooting
Issues with AMD Audio are not uncommon, usually related to the Mic option not working. As far as I am aware there are no AMD specific patches in AppleALC.kext, this is confirmed in the OC Troubleshooting guide linked below.
# AppleALC Miscellaneous issues
The only way I know to fix this issue is for you to create a new Layout-ID that is specific to your Asus Prime B550 motherboard and the ALC887 audio codec. Link below for undertaking this process.
github.com
A more comprehensive guide is linked below.
osxlatitude.com
Just to confirm that any Layout-ID between #11 & 99 are custom ID's for specific use cases/motherboards or laptops.
The generic Layout-ID's #1-7 are more often than not successful in getting the built-in audio working. But they can have issues with specific outputs.
Below is a link to the Info.plist for ALC887, so you can see what I mean by specific use cases.
github.com
Here is a screenshot showing the layout-ID's 11, 12 & 13 from the info.plist. Which tells me that you shouldn't be using Layout-ID 12 for your system, as it is set to work with an Asus Haswell (Intel) motherboard.
Layout-ID's 11, 12 & 13 from AppleALC for ALC887 codec.
# AppleALC Miscellaneous issues
The only way I know to fix this issue is for you to create a new Layout-ID that is specific to your Asus Prime B550 motherboard and the ALC887 audio codec. Link below for undertaking this process.
Adding codec support
Native macOS HD audio for not officially supported codecs - acidanthera/AppleALC
github.com
A more comprehensive guide is linked below.
Complete AppleHDA Patching Guide
Hi friends, This is a complete AppleHDA patching guide for the Audio codec in the Notebooks (but theory works for Desktop too). I'm writing this guide based on my knowledge and experience gained myself doing so many patches and details from the web. Hoping this could help many people looking to p...
Just to confirm that any Layout-ID between #11 & 99 are custom ID's for specific use cases/motherboards or laptops.
The generic Layout-ID's #1-7 are more often than not successful in getting the built-in audio working. But they can have issues with specific outputs.
Below is a link to the Info.plist for ALC887, so you can see what I mean by specific use cases.
AppleALC/Resources/ALC887/Info.plist at master · acidanthera/AppleALC
Native macOS HD audio for not officially supported codecs - AppleALC/Resources/ALC887/Info.plist at master · acidanthera/AppleALC
github.com
Here is a screenshot showing the layout-ID's 11, 12 & 13 from the info.plist. Which tells me that you shouldn't be using Layout-ID 12 for your system, as it is set to work with an Asus Haswell (Intel) motherboard.
Layout-ID's 11, 12 & 13 from AppleALC for ALC887 codec.
